APPENDIX
Appendix 2 Special Register List
249
A
SD4572 High-speed counter preset value [Low-order] (CH3) This register stores the high-speed counter preset value (CH3). R/W
SD4573 High-speed counter preset value [High-order] (CH3)
SD4574 High-speed counter ring length [Low-order] (CH3) This register stores the high-speed counter ring length (CH3). R/W
SD4575 High-speed counter ring length [High-order] (CH3)
SD4576 High-speed counter measurement-unit time [Low-order]
(CH3)
This register stores the high-speed counter measurement-unit
time (CH3).
R/W
SD4577 High-speed counter measurement-unit time [High-order]
(CH3)
SD4578 High-speed counter number of pulses per rotation [Low-
order] (CH3)
This register stores the high-speed counter number of pulses per
rotation (CH3).
R/W
SD4579 High-speed counter number of pulses per rotation [High-
order] (CH3)
SD4590 High-speed counter current value [Low-order] (CH4) This register stores the high-speed counter current value (CH4). R/W
SD4591 High-speed counter current value [High-order] (CH4)
SD4592 High-speed counter maximum value [Low-order] (CH4) This register stores the high-speed counter maximum value
(CH4).
R/W
SD4593 High-speed counter maximum value [High-order] (CH4)
SD4594 High-speed counter minimum value [Low-order] (CH4) This register stores the high-speed counter minimum value
(CH4).
R/W
SD4595 High-speed counter minimum value [High-order] (CH4)
SD4596 High-speed counter pulse density [Low-order] (CH4) This register stores the high-speed counter pulse density (CH4). R/W
SD4597 High-speed counter pulse density [High-order] (CH4)
SD4598 High-speed counter rotation speed [Low-order] (CH4) This register stores the high-speed counter rotation speed (CH4). R/W
SD4599 High-speed counter rotation speed [High-order] (CH4)
SD4600 High-speed counter preset control switch (CH4) This register stores the high-speed counter preset control switch
(CH4).
R/W
SD4602 High-speed counter preset value [Low-order] (CH4) This register stores the high-speed counter preset value (CH4). R/W
SD4603 High-speed counter preset value [High-order] (CH4)
SD4604 High-speed counter ring length [Low-order] (CH4) This register stores the high-speed counter ring length (CH4). R/W
SD4605 High-speed counter ring length [High-order] (CH4)
SD4606 High-speed counter measurement-unit time [Low-order]
(CH4)
This register stores the high-speed counter measurement-unit
time (CH4).
R/W
SD4607 High-speed counter measurement-unit time [High-order]
(CH4)
SD4608 High-speed counter number of pulses per rotation [Low-
order] (CH4)
This register stores the high-speed counter number of pulses per
rotation (CH4).
R/W
SD4609 High-speed counter number of pulses per rotation [High-
order] (CH4)
SD4620 High-speed counter current value [Low-order] (CH5) This register stores the high-speed counter current value (CH5). R/W
SD4621 High-speed counter current value [High-order] (CH5)
SD4622 High-speed counter maximum value [Low-order] (CH5) This register stores the high-speed counter maximum value
(CH5).
R/W
SD4623 High-speed counter maximum value [High-order] (CH5)
SD4624 High-speed counter minimum value [Low-order] (CH5) This register stores the high-speed counter minimum value
(CH5).
R/W
SD4625 High-speed counter minimum value [High-order] (CH5)
SD4626 High-speed counter pulse density [Low-order] (CH5) This register stores the high-speed counter pulse density (CH5). R/W
SD4627 High-speed counter pulse density [High-order] (CH5)
SD4628 High-speed counter rotation speed [Low-order] (CH5) This register stores the high-speed counter rotation speed (CH5). R/W
SD4629 High-speed counter rotation speed [High-order] (CH5)
SD4630 High-speed counter preset control switch (CH5) This register stores the high-speed counter preset control switch
(CH5).
R/W
SD4632 High-speed counter preset value [Low-order] (CH5) This register stores the high-speed counter preset value (CH5). R/W
SD4633 High-speed counter preset value [High-order] (CH5)
SD4634 High-speed counter ring length [Low-order] (CH5) This register stores the high-speed counter ring length (CH5). R/W
SD4635 High-speed counter ring length [High-order] (CH5)
SD4636 High-speed counter measurement-unit time [Low-order]
(CH5)
This register stores the high-speed counter measurement-unit
time (CH5).
R/W
SD4637 High-speed counter measurement-unit time [High-order]
(CH5)
No. Name Description R/W
