APPENDIX
Appendix 2 Special Register List
267
A
SD10778 Connection No.2 protocol execution count Stores the number of protocol executions in connection No.2.
0: Protocol not executed
1 to 65535: Number of executions
R
SD10779 Connection No.2 protocol cancellation specification Cancels the protocol executed in connection No.2.
0: No cancellation instruction
1: Cancellation request (set by user)
2: Cancellation completed (set by system)
R/W
SD10780 Connection No.3 protocol execution status Stores the status of the protocol being executed at connection
No.3.
0: Unexecuted
1: Waiting for transmission
2: Sending
3: Waiting for data reception
4: Receiving
5: Execution completed
R
SD10782 Connection No.3 received data verification result (receive
packet No.1)
Stores the verification results of receive packet No.1.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10783 Connection No.3 received data verification result (receive
packet No.2)
Stores the verification results of receive packet No.2.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10784 Connection No.3 received data verification result (receive
packet No.3)
Stores the verification results of receive packet No.3.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10785 Connection No.3 received data verification result (receive
packet No.4)
Stores the verification results of receive packet No.4.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10786 Connection No.3 received data verification result (receive
packet No.5)
Stores the verification results of receive packet No.5.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10787 Connection No.3 received data verification result (receive
packet No.6)
Stores the verification results of receive packet No.6.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10788 Connection No.3 received data verification result (receive
packet No.7)
Stores the verification results of receive packet No.7.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10789 Connection No.3 received data verification result (receive
packet No.8)
Stores the verification results of receive packet No.8.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10790 Connection No.3 received data verification result (receive
packet No.9)
Stores the verification results of receive packet No.9.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10791 Connection No.3 received data verification result (receive
packet No.10)
Stores the verification results of receive packet No.10.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10792 Connection No.3 received data verification result (receive
packet No.11)
Stores the verification results of receive packet No.11.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10793 Connection No.3 received data verification result (receive
packet No.12)
Stores the verification results of receive packet No.12.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10794 Connection No.3 received data verification result (receive
packet No.13)
Stores the verification results of receive packet No.13.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10795 Connection No.3 received data verification result (receive
packet No.14)
Stores the verification results of receive packet No.14.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10796 Connection No.3 received data verification result (receive
packet No.15)
Stores the verification results of receive packet No.15.
E
lement No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10797 Connection No.3 received data verification result (receive
packet No.16)
Stores the verification results of receive packet No.16.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
No. Name Description R/W
