APPENDIX
Appendix 2 Special Register List
SD5042 Pulse width measurement falling ring counter value [Low-
order] (CH2)
This register stores the pulse width measurement falling ring
counter value (CH2).
R/W
SD5043 Pulse width measurement falling ring counter value [High-
order] (CH2)
SD5044 Pulse width measurement latest value [Low-order] (CH2) This register stores the pulse width measurement latest value
(CH2).
R/W
SD5045 Pulse width measurement latest value [High-order] (CH2)
SD5046 Pulse width measurement maximum value [Low-order]
(CH2)
This register stores the pulse width measurement maximum
value (CH2).
R/W
SD5047 Pulse width measurement maximum value [High-order]
(CH2)
SD5048 Pulse width measurement minimum value [Low-order]
(CH2)
This register stores the pulse width measurement minimum value
(CH2).
R/W
SD5049 Pulse width measurement minimum value [High-order]
(CH2)
SD5050 Pulse width measurement cycle latest value [Low-order]
(CH2)
This register stores the pulse width measurement cycle latest
value (CH2).
R/W
SD5051 Pulse width measurement cycle latest value [High-order]
(CH2)
SD5052 Pulse width measurement cycle maximum value [Low-
order] (CH2)
This register stores the pulse width measurement cycle maximum
value (CH2).
R/W
SD5053 Pulse width measurement cycle maximum value [High-
order] (CH2)
SD5054 Pulse width measurement cycle minimum value [Low-
order] (CH2)
This register stores the pulse width measurement cycle minimum
value (CH2).
R/W
SD5055 Pulse width measurement cycle minimum value [High-
order] (CH2)
SD5060 Pulse width measurement rising ring counter value [Low-
order] (CH3)
This register stores the pulse width measurement rising ring
counter value (CH3).
R/W
SD5061 Pulse width measurement rising ring counter value [High-
order] (CH3)
SD5062 Pulse width measurement falling ring counter value [Low-
order] (CH3)
This register stores the pulse width measurement falling ring
counter value (CH3).
R/W
SD5063 Pulse width measurement falling ring counter value [High-
order] (CH3)
SD5064 Pulse width measurement latest value [Low-order] (CH3) This register stores the pulse width measurement latest value
(CH3).
R/W
SD5065 Pulse width measurement latest value [High-order] (CH3)
SD5066 Pulse width measurement maximum value [Low-order]
(CH3)
This register stores the pulse width measurement maximum
value (CH3).
R/W
SD5067 Pulse width measurement maximum value [High-order]
(CH3)
SD5068 Pulse width measurement minimum value [Low-order]
(CH3)
This register stores the pulse width measurement minimum value
(CH3).
R/W
SD5069 Pulse width measurement minimum value [High-order]
(CH3)
SD5070 Pulse width measurement cycle latest value [Low-order]
(CH3)
This register stores the pulse width measurement cycle latest
value (CH3).
R/W
SD5071 Pulse width measurement cycle latest value [High-order]
(CH3)
SD5072 Pulse width measurement cycle maximum value [Low-
order] (CH3)
This register stores the pulse width measurement cycle maximum
value (CH3).
R/W
SD5073 Pulse width measurement cycle maximum value [High-
order] (CH3)
SD5074 Pulse width measurement cycle minimum value [Low-
order] (CH3)
This register stores the pulse width measurement cycle minimum
value (CH3).
R/W
SD5075 Pulse width measurement cycle minimum value [High-
order] (CH3)
SD5080 Pulse width measurement rising ring counter value [Low-
order] (CH4)
This register stores the pulse width measurement rising ring
coun
ter value (CH4).
R/W
SD5081 Pulse width measurement rising ring counter value [High-
order] (CH4)
No. Name Description R/W
