APPENDIX
Appendix 4 Parameter List
Module parameters
Ethernet Port
485 Serial Port
MELSOFT Connection
Non-Protocol Communication
MC Protocol
Classification-Level 1 Classification-Level 2 Classification-Level 3
Basic Settings Own Node Settings IP Address
External Device Configuration External Device Configuration
Application Settings Security Disable Direct Connection with MELSOFT
Do Not Respond to CPU Module Search
Classification-Level 1 Classification-Level 2 Classification-Level 3
Basic Settings Communication Protocol Type Communication Protocol Type
Classification-Level 1 Classification-Level 2 Classification-Level 3
Basic Settings Communication Protocol Type Communication Protocol Type
Advanced Settings Data Length
Parity Bit
Stop Bit
Baud Rate
Header
Header Setting Value
Terminator
Terminator Setting Value
Control Mode (RS-232C)
Control Mode (RS-485)
Sum Check Code
Control Procedure
Fixed Setting 8 bit Process Mode 8 Bit Processing Mode
Time-out Period Time-out Period
SM/SD Setting Latch Setting Advanced Settings
8 Bit Process Mode
Time-out Period
Header Setting Value
Terminator Setting Value
FX3 Series Compatibility SM/SD for Compatible
Classification-Level 1 Classification-Level 2 Classification-Level 3
Basic Settings Communication Protocol Type Communication Protocol Type
Advanced Settings Data Length
Parity Bit
Stop Bit
Baud Rate
Sum Check Code
Fixed Setting Station Number Station Number
Message Pattern Message Pattern
Time-out Period Time-out Period
