APPENDIX
Appendix 2 Special Register List
265
A
SD10714 Number of registered predefined protocols Stores the protocol number of the registered protocol setting data. R
SD10722 Predefined protocol registration (1 to 16) Whether protocol setting data is registered or not is stored. R
SD10723 Predefined protocol registration (17 to 32)
SD10724 Predefined protocol registration (33 to 48)
SD10725 Predefined protocol registration (49 to 64)
SD10740 Connection No.1 protocol execution status Stores the status of the protocol being executed at connection
No.1.
0: Unexecuted
1: Waiting for transmission
2: Sending
3: Waiting for data reception
4: Receiving
5: Execution completed
R
SD10742 Connection No.1 received data verification result (receive
packet No.1)
Stores the verification results of receive packet No.1.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10743 Connection No.1 received data verification result (receive
packet No.2)
Stores the verification results of receive packet No.2.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10744 Connection No.1 received data verification result (receive
packet No.3)
Stores the verification results of receive packet No.3.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10745 Connection No.1 received data verification result (receive
packet No.4)
Stores the verification results of receive packet No.4.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10746 Connection No.1 received data verification result (receive
packet No.5)
Stores the verification results of receive packet No.5.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10747 Connection No.1 received data verification result (receive
packet No.6)
Stores the verification results of receive packet No.6.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10748 Connection No.1 received data verification result (receive
packet No.7)
Stores the verification results of receive packet No.7.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10749 Connection No.1 received data verification result (receive
packet No.8)
Stores the verification results of receive packet No.8.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10750 Connection No.1 received data verification result (receive
packet No.9)
Stores the verification results of receive packet No.9.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10751 Connection No.1 received data verification result (receive
packet No.10)
Stores the verification results of receive packet No.10.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10752 Connection No.1 received data verification result (receive
packet No.11)
Stores the verification results of receive packet No.11.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10753 Connection No.1 received data verification result (receive
packet No.12)
Stores the verification results of receive packet No.12.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10754 Connection No.1 received data verification result (receive
packet No.13)
Stores the verification results of receive packet No.13.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10755 Connection No.1 received data verification result (receive
packet No.14)
Stores the verification results of receive packet No.14.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10756 Connection No.1 received data verification result (receive
packet No.15)
Stores the verification results of receive packet No.15.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
SD10757 Connection No.1 received data verification result (receive
packet No.16)
Stores the verification results of receive packet No.16.
Element No. where the verification result did not match (b0 to b7)
The cause of mismatch (verification result code) (b8 to b15)
R
No. Name Description R/W
