1 Install and cable a G600 cabinet
Install and wire telephones and other equipment
102 S8100 Installation and Upgrades
November 2003
Table 9: Wiring color code
Station type Wire color
(tip/ring)
Analog yellow/blue
2-wire DCP white/orange
4-wire DCP red/blue
red/orange
Hybrid white/blue
white/orange
white/green
Power white/red
Table 10: Stations connections
Station type Connector
Analog or 2-wire DCP T=1, R=26
BRI T=1, R=26
T1=3, R1=28
4-wire DCP T=2, R=27
T1=3, R1=28
Hybrid T=1, R=26
T1=2, R1=27
T2=3, R2=28
Power 4, 29
