CHAPTER 11 CONTROL SUB FUNCTIONS
11
11.9 Accumulated Pulse Error Detection Function
11.9.2 Setting the accumulated pulse error detection function
Ex.
When the setting values are as follows:
• Alert output accumulated pulse setting value (maximum value): 1200
• Immediate stop accumulated pulse setting value (maximum value): 1100
Both alert output accumulated pulses and immediate stop accumulated pulses are judged by
accumulated pulses that are 1.1 times of the reference value (maximum value). Thus, an alert is output
and the positioning stops simultaneously.
(c) Alert output accumulated pulse setting value, immediate stop accumulated pulse
setting value, and "Accumulated pulse setting" in the switch setting
The setting range of " Alert output accumulated pulse setting value (maximum value)" and " Alert
output accumulated pulse setting value (minimum value)" is 1000 to 50000 (1 to 50 times). However, when the
alert output accumulated pulses exceed the amount of "Accumulated pulse setting" in the switch setting, an
alert is output according to the setting of "Accumulated pulse setting"
The above is applicable to " Immediate stop accumulated pulse setting value (maximum value)" and
" Immediate stop accumulated pulse setting value (minimum value)".
Ex.
When the measured reference value (maximum value) is 2000 and the setting values are as follows:
• "Accumulated pulse setting" in the switch setting: -3700 to 3700 [selection 1]
• Alert output accumulated pulse setting value (maximum value): 3000 (3 times)
The calculated value of alert output accumulated pulses (maximum value) is 6000 (2000 + (3000 - 1000)
× 2000 1000). However, the value of alert output accumulated pulses (maximum value) becomes 3700
because the calculated value exceeds the amount of "Accumulated pulse setting"
Cd.13
Cd.14
Cd.13
Cd.15
Cd.14
Cd.16
Cd.13
