8 ZERO POINT RETURN CONTROL
Zero point return auxiliary functions
Refer to section "3.3.4 Combination of D75P2 main functions and auxiliary
functions" for details on "auxiliary functions" that can be combined with zero point
return control. Also refer to "Chapter 12 CONTROL AUXILIARY FUNCTIONS" for
details on each auxiliary function.
[Remarks]
The following two auxiliary functions are only related to machine zero point
returns.
Auxiliary function name
Machine
zero point
return
Data setting
method zero
point return
High-speed
zero point
return
Reference
Zero point return retry function
Section
12.2.1
Zero point shift function
Section
12.2.2
: Combination possible, : Restricted, : Combination not possible
When a zero point return is not required
Control can be carried out ignoring the "zero point return request flag" (RX(n+1)F,
RX(n+4)F) in systems that do not require a zero point return.
In this case, the "zero point return parameters (
Pr.45 to Pr.58 )" must all be set
to their initial values or a value at which an error does not occur.
Zero point returns from peripheral devices
"Machine zero point returns" and "high-speed zero point returns" can be executed
from the AD75 software package test mode.
Refer to the AD75 software package operating manual for details on zero point
returns from the AD75 software package.
