3 SPECIFICATIONS AND FUNCTIONS
Setting value Default value
Addresses
Axis 1 Axis 2
Set with a decimal.
K
Positioning data No.
Setting
value
: Positioning data No.
: Block start designation
: Indirectly specification
: Machine zero point return
: High-speed zero point return
: Current value change
: Absolute position restoration
: Data setting method zero point
return
· 1 to 600
· 7000 to 7010
· 8001 to 8050
· 9001
· 9002
· 9003
· 9900
· 9901
0 RWwm RWwm+8
Set with a decimal.
K
Override value (%)
1 to 300
Setting value
100 RWwm+1 RWwm+9
Set with a decimal.
R
10
n
Unit conversion table
(New current value)
Example)
n
1
5
inch
5
degree
0
pulse
Unit
Actual
value
Conversion
into integer
n
2
mm/min
3
inch/min
3
degree/min
0
pulse/s
Unit
Unit conversion table
(New speed value)
Setting value
(Decimal)
When setting "10000.00 mm/min" to a
new speed value, set "1000000" to the
remote register.
New current value
New speed value
m
0
RWwm+2
RWwm+3
RWwm+10
RWwm+11
0
RWwm+4
RWwm+5
RWwm+12
RWwm+13
