12 - 68
MELSEC-
A
12 CONTROL AUXILIARY FUNCTIONS
NO
YES
I
II
End
Confirm the completion of the writing.
Turn OFF the remote station
READY signal. [RX(n+7)B]
Carry out a writing request to
the flash ROM.
End teaching?
Confirm the completion of the writing.
Confirm that the buffer memory address [1106] has become 0.
Confirm that the buffer memory address [1138] has become 0.
Set 1 in the buffer memory address [1138].
• • • • • • • •
• • • • • • • •
• • • • • • • •
